MAKITA B-52750 Tungsten Carbide Burr 10x20x6mm SC Diamond Cut
MAKITA B-52750 Tungsten Carbide Burr 10x20x6mm SC Diamond Cut
In stock
What’s Included
- 1 x Makita B-52750 TC Burr 10x20x6mm SC Diamond Cut
Product Overview
The Makita B-52750 is a precision-engineered Tungsten Carbide burr that combines a "Ball Nosed Cylindrical" (SC) profile with a sophisticated "Diamond Cut" geometry. Unlike standard single-cut accessories, the diamond cut pattern features cutting edges running in two opposing directions. This cross-cut design is highly effective at breaking down swarf into granular chips rather than long strands, resulting in significantly reduced operator vibration and a superior surface finish. Ideally suited for complex shaping tasks, the ball-nosed tip allows for the smooth grinding of radii and contours without the risk of digging in, making it a top choice for working on hard materials like stainless steel and ferrous alloys.
Part No: B-52750(MAKACB-52750)
Features & Benefits
- Diamond Cut Geometry: The cross-cut tooth pattern effectively breaks chips into small, manageable particles, preventing tool loading and ensuring a smoother surface finish.
- Enhanced Control: The opposing cutting angles reduce the "pulling" action often felt with standard burrs, offering greater stability and reduced vibration during use.
- Ball Nosed Profile (SC): The radiused cylindrical head is perfect for machining fillets, round-bottomed grooves, and contoured surfaces where a square edge would cause damage.
- High-Endurance Carbide: Manufactured from high-grade Tungsten Carbide to withstand the heat and stress of grinding tough metals, ensuring a long service life.
- Clean Material Removal: Designed to produce a finer finish than standard cut burrs, reducing the need for extensive secondary polishing or sanding.
- Standard Shank Compatibility: Features a precision-ground 6 mm shank, ensuring a safe and concentric fit with standard pneumatic and electric die grinders.
Technical Specification
- Head Diameter (D): 10 mm
- Working Length (Head Length): 20 mm
- Shank Diameter (S): 6 mm
- Shape Code: SC (Ball Nosed Cylindrical)
- Cut Type: Diamond Cut
- Material: Tungsten Carbide (TC)
- Application: Stainless Steel, Ferrous and Non-ferrous Metals
